Cosmos - Model SH-WAD/NDIR -Gas Detector
The SH-WAD range gas detectors have become the standard safety solutions for many production facilities and research centres. They are not only used in cleanrooms but also very useful in many other hazardous environments. The SH-WAD gas detectors can be equipped with universal plug-in modules for the provision of additional functions and communication protocols.
All units comply with the most stringent quality standards and are extremely reliable. With the integrated self diagnostics functions you are quickly notified on any possible disruption. In-Control Software will provide access to additional information about any changes in the status of the unit. By using an overall data-acquisition and monitoring system like SIMS-NX it is even possible to monitor the status of all detectors real-time. In this way there will never be a lack of clarity or information in case of an event.
The SH-4001-WAD/NDIR gas detector is a suction type detector with a infrared (IR) type sensors. The sensor detects next to N2O Nitrous oxide at 0-300ppm other gases like sulfer hexafluride (SF6), carbon tetrafluoride CF4 or trifluoromethane (R-23) (CHF3) .
- Ideal for cleanroom applications
- Integrated alarm handling
- Optional Profibus-DP, Modbus and SIMS communication
- Data acquisition by Incontrol Software
- Possible application; Tools, Environmental, MFC box
- In Control configuration software
- Detector model SH-4001-WAD/NDIR
- Gas Sensor type GS-4600IR
- Target gas N2O / 300ppm
- Monitoring confi guration Single point, extractive.
- Detection Principle IR
- Number of gas inlets / outlets 1
- Output signal 4-20 mA, 3 wire screened
- Accuracy +/-10% 2)
- Alarm levels Matrix programmable output relays card optional
- for: Alarm1, Alarm2, Error & Warning.
- Error reporting Low Flow; Low Electrolyte; Sensor Missing
- Communication interfaces RS(front RJ-45 connector) Optional via plugin module:-232; confi guration and diagnostics
- RS-485; Profi bus DP; MODBUS & RS-485; SIMS
- Indicator 140 x 32 dot matrix; blue/green VF display
- Sampling pump Long life DC operated diaphragm pump
- Flow control Optical/ electronic
- Operating temp. 0 - 40° C ; 32 - 104° F
- Operating humidity 20 % - 90% (non condensing)
- Installation Indoor, wall-mount
- Tube connectors In & out; 1/4 “ R Female
- Power requirements 24 Volts DC
- Power consumption (max.) 25 Watt
- Dimensions (WxHxD) 356 x 164 x 194 mm
- Weight (approx.) 4.0 kg
- Country of origin The Netherlands
