GasBadge - Model Pro -Gas Detector

Built to Industrial Scientific’s highest quality and reliability standards, GasBadge® Pro provides a lifetime of gas hazard protection with more features than any other single gas monitor available. Interchangeable “smart” sensors enable the GasBadge Pro to be quickly adapted to monitor unsafe levels of oxygen or any one of the following toxic gases: carbon monoxide, hydrogen sulfide, nitrogen dioxide, sulfur dioxide, chlorine, chlorine dioxide, phosphine, ammonia, hydrogen cyanide and hydrogen. GasBadge Pro communicates directly via an infrared interface to optional accessories like the DSX Docking Station, Datalink and infrared printer to further simplify and automate calibration, function (bump) testing and data downloading. Standard STEL and TWA readings, and datalogging of up to one year of survey data are featured along with an event-logger that records the past 15 alarm events.

Housed in a rugged enclosure, the monitor is immune to RF, water resistant and extremely durable. A protective concussion-proof overmold protects the unit from extreme abuse in a variety of harsh industrial environments. It’s simple and intuitive four-button navigation allows easy access to setup, operation and calibration functions.

Instrument Warranty
Guaranteed for Life™ – Instrument is warranted for as long as supported by Industrial Scientific Corporation (excluding sensors, batteries, and filters). CO, H2S, and O2 sensors are warranted for 2 years. All other sensors warranted for 1 year

Case
Rugged, water-resistant polycarbonate shell with protective concussion-proof overmold. RFI resistant.

Dimensions
9.4 x 5.08 x 2.79 mm (3.7 x 2 x 1.1 in )

Weight
85 g (3 oz)

Sensors
CO, H2S, O2, NO2, SO2,
NH3, CI2, CIO2, PH3, HCN, H2, CO/H2 Low

Measuring Ranges
CO: 0-1,500 ppm in 1 ppm increments
CO/H2 low: 0-1,500 ppm in 1 ppm increments
H2S: 0-500 ppm in 0.1 ppm increments
O2: 0-30% by vol in 0.1% increments
NO2: 0-150 ppm in 0.1 ppm increments
SO2: 0-150 ppm in 0.1 ppm increments
NH3: 0-500 ppm in 1 ppm increments
Cl2: 0-100 ppm in 0.1 ppm increments
ClO2: 0-1 ppm in 0.01 ppm increments
PH3: 0-10 ppm in 0.01 ppm increments
HCN: 0-30 ppm in 0.1 ppm increments
H2: 0-2,000 ppm in 1 ppm increments

Display
Custom LCD with graphical icons for easy use; Segmented display for direct gas readings; Backlight for low light conditions; “Go/No Go” display mode; Peak reading indication

Alarms
User selectable low and high alarms
Ultra-bright LEDs, loud audible alarm (95 dB) and vibrating alarm

Battery Run Time
User replaceable 3V, CR2 Lithium battery, 2,600 hour run time, typical

Data Logging
1 year continuous storage of data

Event Logger
Continually on. Logs last 15 alarm events, stamping how long ago the event occurred, the duration of the event, and the peak reading seen during the event.

Event-logger can be viewed on PC or printed directly from the instrument to an infrared printer.

Temperature Range
-40 ºC to 60 ºC (-40 ºF to 140 ºF), typical

Humidity Range
0% to 99% RH (non-condensing), typical

IP Rating
Third-party certified IP64

Certifications
ANZEx: Ex ia I/IIC T4
ATEX: Ex ia I/Ex ia IIC T4; Equipment Group/Category I M1/II 1G
China Ex: Ex ia I/IIC T4
CMA: Ex ia I
CSA: Cl I, Gr A-D, T4; Ex ia IIC T4
KC: Ex ia I/IIC T4
IECEx: Ex ia I/IIC T4
INMETRO: Ex ia IIC T4
UL: Cl I, Div 1, Gr A-D, T4; Cl II, Gr E-G
