GemmeCotti - Model HTP -Rotary Vane Mag Drive Pumps

Anti-corrosion industrial pumps suitable for pumping hydrocarbons, solvents, heat transfer oils, refrigerants, cryogenics and radioactive liquids.

• Materials available: AISI 316.
• Materials in contact with the liquid:
  pump body, end cover and rotor: AISI 316;
  o-ring: EPDM/VITON; carbon graphite stator.
• Max flow: 2100 l/h. Max pressure 13 bar.
• Temperature range: from – 70°C to + 200°C.
• Max viscosity: 2000 cPs.
• System Pressure 25 bar at 20°C.
• Available in ATEX version for zone 1 II3G and zone 2 II3G (pump mod. EM-P).
