Gester - Model GT-UA01 -Dual Column Computerized UTM Universal Tensile Testing Machine

• The power system: servo motor and servo drivers and worm gear and rod reducer and ball screw.
• Control system: adopting Pulse Command control method, it will be more accuracy and easy to control.
• The Utm Machine speed control range: 0.001-1000 - mm/min.
• The intermediate plate adjustment is both fast coarse and slow fine-tuning.
• It will return to original site and save automatically testing.
• Data transmission mode: RS232 transmission.
• Utm Universal Testing Machine display mode: computer screen display.
• This universal material testing machine can realize constant speed, positioning, constant power, constant stroke control mode and multilevel control mode which can meet the test requirements of the ordinary.
• Testing space: test width is 400 mm (standard)
• Al plate walking space: 1400 mm {excluding fixture, according to the customer requirements ).
• The entire displacement: the encoder is 1800 P/R, it can improve 4 times accuracy
• Using the LINE DRIVE encoder strong anti-interference ability displacement resolution 0.001 mm.
• Computerized Universal Testing Machine Safety device: overload emergency stop device, up and down stroke limit device, leakage automatic blackout system, automatic break point stop function.

This universal testing machine is designed for conduct tensile, compression, bending, shearing, bonding strength, peeling, tearing and other tests for rubber, plastic, leather, metal, nylon line, fabric, paper, aviation, packaging, construction, petrifaction, electrician, vehicle and other materials.
