+GF+ - Model 2290 -Non-EX Non-Contacting Radar
Tank level measurement – simply with the right sensor. The wide range of tanks, process liquids and conditions requires appropriate technologies to provide consistent filling level information. The radar level transmitter type 2290 combines all advantages of a radar level transmitter in one non-contacting, compact and economical unit. Type 2290 is available in a variety of different materials to resist even the most corrosive environments.
Most popular related searches
radar level transmitter
water treatment pump
water treatment pumping
tank level monitoring
drinking water monitoring
level transmitter
reaction vessel
level monitoring
sludge handling
water conditioning
- General - Challenging tank applications where other non-contacting principles fail e.g. ultrasonic
- Chemical Process Industry - Storage of solvents, chlorine or ammonia. Level detection in reaction vessels or buffer tanks
- Water Treatment - Pumping stations, sludge handling, drain level monitoring, drink water conditioning vessels
Remark:
- Display: LCD
- 99 point customizable linearization
- Large graphical LCD display
- Tank mapping function to ignore internal obstructions
- 19° beam angle, 25 GHz K-band
- Non-contact TDR radar
- Predefined tank shapes
- Distance, volume or mass measurements
- Minimum dielectric constant of process media εr 1.9
- Short dead band of 0.2m (7.8 inch)
- Suitable for hydrocarbons, acids and aggressive media
- For most liquids, including flammable and fuming fluids
- Liquids which tend to foam e.g. in acid neutralization applications
- CE
- IECEx
- RoHS Compliant
- FCC
-
ATEX
