Valco - Model 503 -Globe Valve
FromVALCO Group
Excellent tightness thanks to their double ball joint design. Full passage.
Most popular related searches
globe valve
pneumatic actuator
hydraulic actuator
stop valve
electric actuator
sealing system
pipe cleaning
tank bottom valve
sampling valve
dome valve
- DN: 15 to 250
- NPS: 1/2 to 10
- PN: 10 to 420
- Class: 150 to 2500
Functionality
- Tank or reactor bottom outlet valve
- Feeding valve : side mounted or upright
- Sampling or injection valve : at tank bottom or laterally / on a section of piping
- Walls cleaning by spraying or streaming : installed on reactor dome
- In-line stop valve, no dead areas
Manufacturing
MATERIALS
Carbone Stell, Stainless steel, Duplex/Superduplex, Titanium, Zirconium, Uranus, Nickel, Hastelloy, Monel
CONSTRUCTION
Fabricated (Welded), Cast
SEALING SYSTEM
- Conical metal-to-metal piston seating
- Radial soft seating with packing, O’ring, etc.
- Handwheel,
- Gearbox,
- Dead-man handle,
- Double acting pneumatic actuator,
- Single acting pneumatic actuator,
- Hydraulic actuator,
- Electric actuator
CLOSING DEVICE
- Piston with conical seating, straight piston
