Forrec - Model FML Series -Granulators

• Soundproof loading hopper with protective measures in order to avoid the expulsion of material externally, suitable for loading using a conveyor belt
• Cutting chamber in top quality large steel sheeting assembled with screws and pins in order to render worn parts easily replaceable
• Double row spherical roller bearings housed in supports connected for the entire circumference to the grinding chamber with a relief and equipped with grease nipples
• Arrangement of water cooling for the cutting chamber
• Configuration of the scissor cut obtained with the inclination of the rotating blades in respect to the counter blades
• Tempered chrome k110 blades and counter blades (58/59 HRC), rectified and micro metrically adjustable
• Blades and counter blades adjustable on the bench with a template in order to always maintain optimal cutting
• Conditions and distance between the blades and between the rotor blades and the grille, as well as a reduction in replacement times
• Reversible sorting grille with a large exhaust area mounted on a cradle grille holder which renders cleaning and replacement easy
• Solid flywheel fastened to the shaft rotor with expanding shrink disks which guarantee a reliable fastening over time funnel container for ground waste, extractable and designed for attachment to a suction plant
• Support base made of sturdy steel profiles mounted on anti vibration devices
• Electric motor with star-triangle starting system - trapezoidal transmission belts

Production:
300 to 800 kg/h

Rotor:
open or closed

Engine:
30 kW / 37KW / 45KW

Rotor length:
600 – 900 - 1200 mm

Fan engine:
4 kW

Rotating blades:
3 or 5

Rotor diameter:
450 mm

Fixed blades:
2

• Medium-large sized waste from the injection moulding process
• Medium-large sized waste from the blow moulding process
• Extrusion parts (pipes, profiles, plates, drains)
• Film in bulk or on reels
• Thermoforming reels
