Warman pump - Model 8/6E-G -Gravel Dredge Slurry Pump
PG/PGH Series Gravel pump are designed with wide flow channel, which are suitable for pumping of highly abrasive slurries that containing large particles. Low NPSH requirement and large volume casing make it the best choice for gravel, dredging and metal smelting slag conveying etc.
Most popular related searches
horizontal centrifugal pumping
horizontal centrifugal pump
dredging slurry pump
abrasive slurry
centrifugal pumping
centrifugal pump
dredge
dredged slurry
slurry pump
dredging
- Single stage, Single Suction, Single casing horizontal centrifugal pump, adopt special clamps clip tight pump body and pump cover. The discharge direction can be oriented in any direction of 360 degrees.
- High rigidity shaft, Grease lubrication bearing. This cartridge bearing assembly design makes the maintenance and replacement of pump parts easier.
- Spacious flow channel, better cavitation performance, robust design ensures long life under sever duties.
- Wet ends are made of abrasive resistant hard metal.
- Seal options: Gland seal(most popular and economical), Expeller seal(Centrifugal or dynamic), Mechanical seal(special and expensive).
- Drive arrangement: Direct drive(DC), V-belt drive(CV, ZV, CR, CL), Gear box, Hydraulic couplings, VFD etc.
