Guntamatic Heiztechnik - Model PRO FLEX 175 to 1000 kW -Industrial Large Pellet System

• Ecologically sound and highly efficient: up to 94 % efficiency
• Industrial step grate technology for regulated ember bed temperature
• Extremely large self-cleaning heat exchanger in proven cupola design
• Long operating cycles without service or cleaning
• Modular design for the highest operational reliability
• Standard industrial product for quick availability
• Possible on-site installation by heating engineers
• Clever safety concept with protection against back burning and temperature monitoring of the fuel store
• Excellent quality and components tested several times
• First class spare parts service from our own production
• Large LED operating display
• Straightforward operation thanks to user-centred touchscreen interface design
• External access via PC or mobile (option)
• Automatic ash discharge with moveable ash box or fully automatic vacuum ash discharge into a 200 litre drum (option)
• Modular construction for easy handling and installation
• First class spare parts supply resulting from series production in house
• Fault menu and separate component tests make analysis and service easier
• Optimum accessibility for service and maintenance

Fuel is gasified with a staged supply of primary air under ideal ember bed temperature conditions. The amount of combustion air and fuel charge is regulated by means of a lambda probe, so that the system achieves an optimum level of efficiency. The released combustion gases are cleanly converted into thermal energy by mixing them with secondary air in a large rotating combustion zone at a temperature of around 1300 °C. The well proven cupola design enables a perfect burnout and long dwell times.

Operational reliability is greatly improved by the multi-stage modular design, particularly where several larger buildings need to be heated. Should one of the boilers connected in series fail, the remaining boilers simply continue to operate. This protects against total failure, which is of particular importance to municipal or commercial users.

Every section of the PRO industrial system can be handled by means of a pallet truck. Its assembly is perfectly straightforward. There are no long-winded assembly and installation steps to take.

Operating the PRO industrial system is especially easy thanks to the well thought-out and user friendly touchscreen interface. All settings and scans of system data can be made in just a few steps.

Apart from their safety and economy, PRO systems offer further advantages, such as their flexible discharge solutions and the option of heating with pellets and woodchips.
