ICT - Model HF4 -Hailflow Sensor for Hail Monitoring
The HF4 HailFlow sensor for Hail Monitoring is a non-mechanical hail sensor. An acoustic instrument, the HF4 enables the detection of hail, characterisation of hailstone size. The sensor is able to distinguish between 15 classes of hailstone diameter, ranging from 0.5 to 8 cm, with a capability of counting up to 25 solid impacts per second. The HF4 is compatible with any SDI-12 logger or IoT Node (such as the MFR-Node or S-Node).
Most popular related searches
The HF4 HailFlow Sensors is:
- Non obstructable
- Instrument with no mobile parts – totally sealed acoustic instrument
- Universal mounting kit available
- Omni-directional – even under the highest winds
- Corrosion free and resistant to the highest winds and the most extreme conditions
- Plug-and-Play or totally configurable – microcontroller inside
- Can be connected to almost any external unit
- SDI-12 and IoT compatible – internal memory
With the hemispherical surface, the measurements cannot be obstructed by dust, dirt, or leaf matter removing the need for ongoing maintenance.
Data output options include:
- SDI-12
- RS485 (accessory required)
- Analogue (0-2.5V or 0-5V)
