Hamilton - Model XYClone -Fixed Laser System
For use in animal IVF and developmental biology procedures. Hamilton Thorne offers the XYClone® fixed lasers and the XYRCOS, XYRCOS DTS (dynamic targeting system) moveable lasers. Our lasers are rated Class 1 safe with 1460 nm in power and pulse durations as low as 1 microsecond.
Our lasers come equipped with the user-friendly HT Laser 6 software.
Intuitive Software Interface
Clean and intuitive design with modernized software interface. Quick-select between laser modes and objectives for maximum efficiency. Review captured images and videos in the gallery.
Isotherm Rings for Temperature Indication
The Isotherm Rings appear on the screen as a series of six concentric circles of varying colors. This safety feature indicates the drill hole size and the maximum temperature reached at the ring diameter. The Isotherm Rings automatically adjust for every power and pulse time combination.
High Resolution Digital Camera
View embryos in full screen and enhanced resolution with the integrated digital camera.
Integrated Database
Store sample details and images to database. Improve workflow with the ability to quickly select sample information for future procedures.
