Shinyei - Model OMX-TDM -Handheld Odor Meter

Handheld Odor Meter is highly sensitive.

• Simple and easy to measure odor
• Just turn the switch on
• Data can be stored up to 511 files
• Data logging function with large capacity
• Data can be graphically illustrated by Data filing software

Handheld Odor Meter OMX-TDM is suitable for detecting TVOC which causes sick house syndrome.

• Display toluene equivalent value in μg/m3.
• No need any complicated preparation for odor measurement.
• Simple and easy to use.
• Detect TVOC in living environment, petrochemical plants and manufacturing factories.
• For odor control, workspace improvement and odor measures for quality control.

Toluene-value Digital Indication
The value is displayed as toluene concentration value.

Simple setting up in advance
The sampling is user-friendly and collecting data in real time.

Start in short time
Measurement starts quickly in 10min.

Model Name: OMX-TDM
Detection Method: One Semiconductor Gas Sensor
Sampling Method: Continuous Sampling with Built-in Air Pump
Object Gas: TVOC (Toluene), etc
Odor Strength Level: 0 - 9999 (ug/m3)
Classification: -
Power: 4×AASize Alkaline Batteries or AC Adaptor
*Battery life for continuous measurement is approx. 7 hours.
Memory Capacity: Up to 32,732 Data
Memory Partition: Up to 511 Files
Operating Temperature: 0 ~ 40?(32-104F) *No Dew Condensation
Storage Temperature: -10 ~ 50?(14-122F) *No Dew Condensation
Dimensions: W74 X L167.5 X D35mm approx.
Weight: 250g approx. (Without Batteries)
Accessories: USB Cable, Air Purifying Unit, Activated Carbon, 4×AA Size Alkaline Batteries, AC Adaptor
