HARSH - Model 7.5t -Heavy-Duty Hookloaders
HARSH Hookloaders are built to carry all types and size of container, from site clearance to landfill, from factories to recycling centres. Moving anything, anywhere, with day-in, day-out reliability. In some of the most arduous and aggressive of all truck-operating environments, such versatility and proven performance count for everything. Designed with a highly advanced technical specification, HARSH Hookloaders offer an exceptionally productive proposition for RORO trucks.
Our range of small Hookloader bodies for 7.5t gvw trucks offers great versatility for easily handling a wide range of loads. With a lightweight design and low hook height, HARSH Hookloaders have exceptional lifting performance and demounting functionality.
An articulating arm is used as standard, with mechanical hook security and a single lift cylinder. Operated safely from inside the vehicle cab. It has a welded hook and external hydraulic locking.
Our HH4 model lifts 4 tonnes and can carry between 3mtr and 3.5mtr containers at 47° – 51° degree tip angle. The larger HH6 model lifts 6 tonnes carrying between 3.8mtr and 4.3mtr containers at 52° degree tip angle.
Depending on the truck chassis, either powerpack or PTO/pump drive options are available.
- 2 year as standard on all fabricated structural items. 1 year parts and labour warranty on hydraulic components and sheeting system parts.
- HITS repair and maintenance service packages available
- HH4 Van – 4-tonne lift model, suits 7.5t gvw
- HH6 Truck – 6-tonne lift model, suits 7.5t gvw
- Powerpack or PTO/pump operation
- Remote-control hook operation
- Ideal with a Hy-Tower hook sheeting system
- On-board weighing compatible
