Heatray Solar - Enclosed Compound Parabolic Concentrator for Water Heating
The Enclosed Compound Parabolic Concentrator by Heatray Solar Pvt. Ltd. is a solar thermal system designed for efficient water heating. It can heat water up to 80°C with a compact design that's easy to transport and install, minimizing handling concerns. The system features a total stainless steel rust-proof body, making it durable. It's effective even under low sunlight, requires less space, and has fewer breakage issues. The unit has a 1.5 m2 aperture, capable of heating approximately 200 liters of water per day at 45-50°C, harnessing around 5000 kCal of energy daily. Up to 20 units can be connected in series, and multiple rows in parallel configuration are possible. The system has a 2 m2 installation footprint per unit. The support stand is made of 35x5 mm thick powder-coated mild steel. The storage tank is provided by the buyer, with compatibility extending to 'Sintex' tanks.Most popular related searches
Our Enclosed Compound Parabolic Concentrator (ECPC) system is inspired by our Compound Parabolic Concentrator which was designed for industrial application. In order to ease the installation difficulty this system was developed later. However due its easy installation we have decided to open it to domestic market as well. Compared other solar water heater it has a lower foot print and High efficiency due to the use of concentrator technology.
- Can heat water up to 80⁰c.
- Compact Design
- Easy to transport
- Easy to install
- Hassle-free handling
- Total SS rust proof body construction
- Better heating performance
- More effective under low sunlight
- Requires less space
- Lesser brakeage issues
- System configuration flexibility
- Cost effective technology
- Unit size: 1.5 m2 aperture
- Average Qty. of hot water at 45-50OC: 200 ltrs/day
- Energy harnessed: 5000 kCal/day/unit
- Max. units could be connected in series:20 units
- Multiple rows in parallel possible if required.
- Installation footprint: 2 m2 per unit
- Support stand Structure made of 35X5 mm thick powder coated MS
- Storage tank is in the scope of buyer.( Even a ‘Sintex’ tank could be used)
