ARA - Model 3240 Series -High Gain Satcom Antennas
The ARA-3240 Series hosts extremely rugged and portable high-gain UHF SATCOM antennas that are available in full and compact sizes. These antennas are ideal for tactical command posts and temporary fixed site applications. The compact version is ideal for operation in high winds. The right-hand circular polarized (RHCP) antenna is designed to operate from 240 to 318 MHz at 200 Watts CW. These antennas are designed with exceptionally high gain, low VSWR, and rapid deployment. The antenna complies with MIL-STD-810G environmental standards for vibration, shock, temperature, loose cargo, and immersion.
Most popular related searches
- Deployment Time: < 3 minutes
- Black Anodized Finish
- Folding Tripod with Azimuth and Elevation Adjustment
- Two 12.5ft RF cables
- Soft or Hard Case
- Standard or Compact Size
- Made in the USA
- Gain 9.7 to 15.0 dBic
- Frequency 240 to 318 MHz
- Polarization Right-Hand Circular
- Impedance 50 Ω
- VSWR < 1.5:1
- Axial Ratio 2 to 3 dB
- Power Handling 200 Watts CW
- Cables Includes two RF RG-213 12.5’ cables with Type-N Male to Type-N Female
