Dearto - Model DTWL -High Precision Thermostatic Chamber

Using constant temperature liquid bath technology, the temperature field is more constant

• Temperature control adopts liquid bath constant temperature and other plate heating technology. After the liquid medium is controlled to a constant temperature in the constant temperature bath, it is circulated to the outside of the working cavity. Through the heat radiation method, the temperature of the working cavity is constant and uniform. The cooling method has a qualitative leap in temperature indicators.

Intelligent

• Integration of measurement technology and internet of things technology, wifi remote control, making measurement easier.
• High-definition touch screen control, multi-touch, greatly improve the user experience.
• One-key start, full automatic control, shorten the training period of measurement personnel.
• Timing switch machine, remote switch machine, save time and improve verification efficiency.

Wide temperature range

• High-precision temperature box series products can provide constant temperature environment within the range of -40 °C -100 °C
• Meet "JJF1407-2013 WBGT Index Meter Thermometer Calibration Regulations"
• Meet "JJF1366-2012 Temperature Data Acquisition Instrument Calibration Specification"

• HD touch:Using high-resolution capacitive screen, the display is clearer, multi-touch support in line with customer mobile phone touch operation habits.
• Wifi controfcMobile phone / pad remotely set the temperature, start and stop the device, read the current temperature value and fluctuation degree and other device status.
• Status prompt:Real-time calculation and display of temperature fluctuation, prompt treach stable state, U disk insertion detection, wifi connection prompt.
• Curve display:Real-time display of temperature curve, support touch zoom and pan operation, one-click screenshot tsave the curve tU disk.
• Data record:The temperature data is automatically saved in xls format arid exported ta USB flash drive with one click.
• Timing boot:The system has the function of timing start-up, which can realize the equipment start-up before work, and start working immediately after work without waiting.
• Multi-point calibration:!! supports multi-point calibration of temperature and humidity sensors, and can perform multipoint corrections on temperature sensors and indications tensure consistency with the standard.
• Segment control:The temperature adopts the segmented PID control scheme, which is fast and stable, and "zero* overshoot.
• Speed regulation of fan:The main circulation fan of the inner cavity adopts frequency conversion speed control, and the fan speed can be set through the touch screen.
• Multiple protection alarm:Constant temperature bath overheat protection, liquid level alarm; compressor overheat alarm, start and stop protection function
• Communication expansion:Equipped with network port, wifi interface, US8 interface, RS-232 interface, can communicate with PC trealize data reading and system setting.
