AndritzModel MP Series -High-Pressure Pumps

SHARE

The high standard of the ANDRITZ multi-stage high-pressure pumps from the MP series is based on decades of experience in designing hydraulic machines and on extensive process know-how. The pumps are installed for conveying clean and slightly contaminated media such as cold and hot water, condensate, deionized water, oils, and suspensions. The high-pressure pumps in the MP pump series are designed according to a strict modular system. With this system, different design variants can be supplied according to the customer‘s requirements quickly, easily and economically, without customizing and using a minimum number of components. For more information on our high-pressure pumps from the MP series please have a look at our brochures in the sidebar or contact us directly.

Most popular related searches
  • Horizontal design with a closed impeller and external bearing assemblies on both sides
  • Axial heat expansion by the pump rotor is absorbed internally without influencing the coupling alignment
  • Easy maintenance
  • Design: multi-stage, closed impellers
  • Head: up to 950 m
  • Flow rate: up to 400 m³/h
  • Pressure: up to 100 bar
  • Temperature: up to 160° C
  • Power: up to 600 kW
