Cacheng - Model CMLJET -Horizontal Multistage Stainless Steel Centrifugal Pump

Operating Conditions:

• Thin, clean, non-flammable and non-explosive
• liquid containing no solid granules and fibers.
• When the density or viscosity of to-be conveyed
• liquid is larger than that of water, it is necessary
• to select a driving motor of high power.
• Liquid temperature:
• standard model:-20?~+70?;
• high temperature:-20?~+104?;
• Ambient temperature:≤+50?
• Max.working pressure:1.0MPa

Motor:

• 2-pole induction motor;
• Single-phase:1x220~240V/50Hz,
• Three-phase: 3x380~415V/50Hz;
• Motors of other voltages are available
• upon request.

Materials:

• Stainless steel middle section.
• Stainless steel impeller CMLJET40-120 PPA self suction cup.
• CMLJET200-600stainless steel self suction cup.

• Water treatment processes.
• Industrial cleaner.
• Water boosting on process, Heating and cooling for industrial process.
• Air-conditioning system, Air freshening, heater device(softwater).
• Fertilization/metering system.
• Water supply and boosting (drinking water, light chlorine water).
