Hada - Model HD-50L-HClO -Hospital Detergent Salt Chlorinator Hypochlorous Acid Machine

SHARE

HD-series automatic hypochlorous acid generator is made up of electrolysis unit, PLC control system, salt water tank, storage tank and other units, which can easily and safely produce high-quality, high-spectrum, safe and non-toxic hypochlorous acid disinfection solution.

Most popular related searches
hypochlorous acid
hypochlorous acid generation
hypochlorous acid disinfection
hypochlorous acid generator
water storage tank
residual chlorine
chlorination
chlorine detection
disinfection system
dosing pump
  1. Salt will be dissolved in the tank and become saturated brine (25%);
  2. Diluted into 3% after filtered ( If use sea water as raw material, it will be treated before electrolysis);
  3. Electrolysis in the host machine;
  4. The final product- hypochlorous acid liquid (5000ppm) in the storage tank;
  5. The hypochlorous acid solution will be injected into the pipe by metering pump;
  6. Residual chlorine detective will monitoring the residual chlorine and return feedback to PLC center;
  7. PLC center will adjust the speed of dosing pump according to the preset standard.
