HCC - Model 400/20 K-GR-E -Hydraulic Dredger
Productivity оf the pulp: 400 m3/h. Productivity оf the soil (hydraulic deposition of soil category 1): 110 m3/hour; 900 m3 for the shift(8 hours). Dimensions: length 11 m, width 2,7 m, height 3,0 m. Weight: 18 t. Hydraulic dredger is equipped with an arrow. Suction pipe length is 15 m with hydraulic washing-out (the water supply is 80 m3 per hour with hydraulic drop of 60 m, pump capacity is 12 kWt).
Most popular related searches
- Slurry pipeline: 100 m (including: 50 m of floating pipeline and 50 m of coastal pipeline), diameter of the pipeline: 160 mm.
- Electric motor of 5AM280S6 brand (capacity of 75 kWt, 1000 rev/min).
- Pump: GRAU 400/20. Pump specifications: 8 inch/6 inch; soil outlet 20% per hour, hydraulic drop of water column– 20 m, maximum capacity – 75 kWt, rotation frequency – 950 rev /min.
- The hydraulic dredger of this modification lifts the soil from the bottom of water basin of 1-15 m, the pushing through slurry pipeline is up to 400 m by horizontal.
- Energy supply: coastal. Movement with the help of winches – 4 power units each 1,5 kWt.
- The enterprise guarantees the operation of the equipment for 1 year or 1800 Moto hours.
- Term of manufacturing is 3 month. Complete package of documents.
