HCC - Model 1600/25-3-GR-E -Hydraulic Dredger
Productivity оf the pulp: 1600 m3/h. Productivity оf the soil (hydraulic deposition of soil category 1): 250 m3/hour; 2000 m3 for the shift(8 hours). Dimensions: length 12 m, width 5 m, height 3 m. Three pontoons. Weight: 25 t. The hydraulic dredger is equipped with an arrow. Suction pipe length is 10 m with hydraulic washing-out (jet) the water supply is 150 m3 per hour with hydraulic drop of 70 m, pump capacity is 32 kWt.
Most popular related searches
- Slurry pipeline: 100 m (including: 50 m of floating pipeline and 50 m of coastal pipeline), diameter of the pipeline: 319 mm.
- Electric motor: DAZO4-450X-8U1 brand (capacity of 315 kWt, 750 rev/min).
- Pump: GRAU 1600/25. Pump specifications: 12 inch/10 inch; soil outlet 20% per hour, hydraulic drop of water column– 25 m, maximum capacity – 315 kWt, rotation frequency – 750 rev./min.
- The hydraulic dredger of this modification lifts the soil from the bottom of water basin of 1-8,5 m, the pushing through slurry pipeline is up to 500 m by horizontal.
- Energy supply: coastal. Movement with the help of winches – 4 power units 2,2 kWt each.
- The enterprise guarantees the operation of the equipment for 1 year or 1800 Moto hours.
- Term of manufacturing is 3,5 months. Complete package of documents.
