HCC - Model 800/40-K-M-GR -Hydraulic Dredger
Productivity оf the pulp: 800 m3/h. Productivity оf the soil (hydraulic deposition of soil category 1): 200 m3/hour; 1600 m3 for the shift(8 hours). Dimensions: length 16 m, width 4,5 m, height 3,0 m. Weight: 25 t. The hydraulic dredger is equipped with an arrow. Suction pipe length is 12 m, with hydraulic washing-out (jet), the water supply is 120 m3 per hour with hydraulic drop of 90 m, pump capacity is 30 kWt.
- Slurry pipeline: 100 m (including: 50 m of floating pipeline and 50 m of coastal pipeline), diameter of the pipeline: 250 mm.
- Auxiliary GNT 55, power 45 kWt, diesel fuel consumption of 20 liters/hour.
- Power unit: D-262.S Specifications: 250 horse-powers, fuel consumption - 25 l/h, rotation frequency - 2000 rev/min.
- Pump: GRAU 800/40. Pump specifications: 10 inch/8 inch; soil outlet 20% per hour, hydraulic drop of water column 40 m, maximum capacity 200 kWt, rotation frequency 750 rev/min.
- The hydraulic dredger of this modification lifts the soil from the bottom of water basin of 1-20 m, the pushing through slurry pipeline is up to 600 m by horizontal.
- Energy supply: self-contained supply. Movement with the help of winches 4 power units 1,5 kWt each.
- The enterprise guarantees the operation of the equipment for 1 year or 1800 Moto hours.
- Term of manufacturing is 4,5 months. Complete package of documents.
Slurry pipeline: 100 m (including: 50 m of floating pipeline and 50 m of coastal pipeline), diameter of the pipeline: 250 mm.
Auxiliary GNT 55, power 45 kWt, diesel fuel consumption of 20 liters/hour.
Power unit: D-262.S Specifications: 250 horse-powers, fuel consumption - 25 l/h, rotation frequency - 2000 rev/min.
Pump: GRAU 800/40. Pump specifications: 10 inch/8 inch; soil outlet 20% per hour, hydraulic drop of water column 40 m, maximum capacity 200 kWt, rotation frequency 750 rev/min.
The hydraulic dredger of this modification lifts the soil from the bottom of water basin of 1-20 m, the pushing through slurry pipeline is up to 600 m by horizontal.
Energy supply: self-contained supply. Movement with the help of winches 4 power units 1,5 kWt each.
The enterprise guarantees the operation of the equipment for 1 year or 1800 Moto hours.
Term of manufacturing is 4,5 months. Complete package of documents.
