HMA - Model 2000 -Hydraulic Earth Pressure Cell

FromHMA Geotechnical a division of the HMA Group

SHARE

The Model 2000 Hydraulic Earth Pressure Cell is fluid filled and connected to any of the series 1000 diaphragm piezometers, which act as the pressure transducer (see model 1100 and 1200 for details). The cells are suitable for measurement of total pressure against walls and in embankments, fills and any other earthen mass. The Model 2050 is similar to the 2000 but is fitted with a post stressing pinch tube, which allows recoupling of the cell to concrete after curing.

Most popular related searches

earth pressure cell

area monitoring

pressure transducer

pressure monitoring

acrylic concrete cure

Hydraulic Earth Pressure Cells are designed to measure stress acting on a plane surface and are typically installed in:

Dams and earth embankments
Foundations, retaining walls and piles
Against pipelines and culverts
Against and under buildings
In railroad ballast
Beneath raft foundations
Paste backfills

Long term stability
High accuracy and sensitivity
Simple installation
Can tolerate long cable lengths
Waterproof design
Fitted with thermistor
Due to inherent high sensitivity it is not necessary to produce a large strain in the area monitored to create stress.
Able to be connected to data logging systems

Pressure ranges: (kPa) 350, 700, 1000, 2000, 3000, 5000
Accuracy: <± 0.5% full scale
Resolution: 0.025% full scale
Operating temperature: -20 to +65C
Connecting tube length: 300mm
Dimension: 230mm, 20mm thick
Weight: 1.8 kg
