Irtec - Model GI/ESRM -Hydraulics With Motor Pump
FromIrtec S.p.A.
All-in-one irrigators ready to lift water before distributing it. The motor pump mounted on the frame allows water to be lifted directly from canals and, if necessary, it is ready as a booster pump.
Most popular related searches
hydraulic motor pump
hydraulic lifting
raingun trolley
hose reel
pressure gauge
booster pump
water distribution
tachometer
epoxy coating
- Hydraulic rotation and hydraulic lifting of drawbar
- Telescopic hydraulic feet
- 4 synchronised speed gearbox
- Power take off
- Turbine flanged on the gearbox with built-in by-pass
- Flexible connection pipe
- Galvanized raingun trolley mounted on variable track wheels
- Raingun
- Set of nozzles REFLEX raingun from Ø 24 to Ø 32
- Set of nozzles EXPLORER raingun from Ø 28 to Ø 40
- Pressure gauge (glycerine bath)
- Winding handle
- Speed equalizer
- Tachometer
- Hydraulic system by rapid couplings to tractor
- Safety guards
- 2 wheels 400/60-15.5 16 PR 6F
- Hot galvanized chassis and reel coated by epoxy resin and painted with polyurethane paints
- Reinforced reel with 16 lateral supports
- Reinforced stabilizer legs
- Safety guards made of steel, swaged galvanized and painted
- Galvanized double water inlet
- Polyethylene hose made by unadulterated raw material
