Ice Qube - Model TE & TEC Series -Inset Mount Thermoelectric Coolers
Ice Qube’s TE & TEC utilize the Peltier effect, which is caused by applying a voltage between two electrodes connected to an electrode material. These types of units are also known to the industry as thermoelectric or TE. Ice Qube’s engineers designed the TE to integrate into your application with an Inset mount. The Inset Mount allows for part of the TE to protrude from the application and part to set inside the application. This design given to the TE by our engineers allows for a lower profile design and integration making it great for space conscious environments.
The controller of the TE is a touch sensitive LCD digital controller named the TEC and is designed to be mounted wherever the integrator may see fit for the application. Thermoelectric cooling is the ideal solution for low-maintenance environments that require 200-300 Watts (682-1024 Btu/h) of closed-loop cooling capacity and want a small solution measuring H 15.94” (405mm) x W 7.09” (180mm) x D 7.52” (191mm).
- UL Certified
- RoHS Compliant
- REACH Compliant
- Telcordia GR-487 Tested (Salt Fog & Wind Driven Rain)
- 200-300 Watts (682-1024 Btu/h) of closed-loop cooling capacity
- Closed-loop cooling to protect your application and increase efficiency
- Compact size of H 15.94” (405mm) x W 7.09” (180mm) x D 7.52” (191mm)
- Mounts on the side or top of enclosure while maintaining NEMA type 12, 3R, 4, or 4X
- Zero Ozone Depletion Potential (ODP)
- Zero Global Warming Potential (GWP)
- Zero possibility of fluid leakage resulting in loss of cooling capacity
- Easy installation
- Indoor and outdoor use
- Powder coated durable 16-gauge welded steel construction
- Designed for use on electrical, electronic, and telecommunications equipment enclosures
- Efficient and environmentally friendly aluminum heat sinks
- Environmentally friendly, quiet, and no fluorocarbons
- Horizontal and Vertical mounting to enclosure
- Space saving aesthetic cabinet design
- Certified by independent certification agencies
- In-house tested via Ice Qube’s testing facilities
- Engineered for optimal engineering efficiency in enclosure cooling
- For indoor or outdoor use
- Custom finishes
- Non-Stocking item in 304 or 316 Stainless Steel Cover (includes NEMA 4X Package)
- 24 VDC
- 48 VDC
