DABECO - Model DB111 -IIC Digital Signal Humidity and Temperature Probe for Interior Usage
The DB111 is a cost-effective humidity probe in an ABS plastic housing with rapid response feature. It is designed for indoor environments without condensation or for integration into other manufacturers' equipment. The probe is wall-mounted. It is ideal for applications where the temperature changes rapidly and standard measurement accuracy is sufficient.Most popular related searches
humidity probe
indoor environment
temperature probe
humidity temperature probe
humidity sensor
temperature and humidity probe
Specification
Measurement Range
Humidity: 0 ~ 100 %RH;
Temperature: - 40 ~ +120 °C (- 40 ~ +248 °F)
Accuracy at 0~90%RH@+25 °C(+77 °F)
Humidity: ±2.0 %RH;
Temperature: ±0.2 °C (31.64 ~ 32.36 °F)
Response Time (T63)
≤8 S
Power Supply Input
2.4 - 5.5 VDC
Working Temperature
-40 ~ 60 °C (- 40 ~ +140 °F)
Working current
≤15mA
Interfaces
I²C
