Lingyu - In Line Compressed Air Filter System with Manual Drain Valve
Lingyu is top manufacturer of in line compressed air filter system in China. And coalescing filter can eliminate many harmful materials from air compressor. For example, it can remove water, dust and oil vapors, etc. In addition, compressed air filters are usually three-stage. That is, it includes primary filter or pre-filter, dust-removal filter and oil-removal filter. Some manufactures call them QPS precision filters. And filtration accuracy is 1.0 micron and 0.01 micron. This filter is with manual drain valve. So you need to drain the water regularly in time. Of course, we also produce compressed air filter system with automatic drain. Additionally, the housing material is cast aluminum alloy. And we can also customize other materials, such as carbon steel and stainlss steel.
The advantages of our compressed air filter system:
- Firstly, use multiple layers of different filter materials. That is, it includes borosilicate fiber layer, glass fiber layer, activated carbon fiber layer, multi-layer non-woven fabric layer and stainless steel mesh layer. As a result, we can obtain high-quality air. Besides, it can ensure the working strength of the filter element.
- Secondly, use one-piece cast aluminum housing. Moreover, it passes the internal electrophoresis treatment. There sprays the epoxy resin powder on the outer surface. In addition, it passes twice pressure tests. So it guarantees durability and corrosion resistance. At the same time, prevent in line compressed air filter leakage.
- Thirdly, there is deflector inside the filter element. So it makes the air delivery smoother. There is less differential pressure. Therefore, it will reduce energy consumption of the compressed air filter system.
- Fourth, the air flow direction is marked on the housing. Very easy to install.
- Fifth, the compressed air line filter is with a manual drain valve. Stable and reliable. We can drain the water regularly.
- Sixth, we can customize the logo and label for your filters.
- Finally, the packaging is good. Use pearl wool for individual protection. So it can prevent shipping damage.
The filter element adopts a straight-through open design. Therefore, the impurities can be directly sent to the liquid storage chamber. No need to penetrate through the filter element. Finally we discharge them through the drain valve.
The middle filter element adopts high-quality polymer filter material. It has a certain adsorption capacity for impurities such as oil mist. So it fully guarantees the filtering effect. Part of the compressed air purges the inner wall from top to bottom. So it can effectively eliminate impurities. At the same time, it reduces the resistance of the filter element to the compressed air.
Solid and liquid droplets are intercepted by in line compressed air filter. Then agglomerates on the surface of the filter element (inside and outside). They settle to the bottom of the coalescing filter by gravity. Finally, we exhaust impurities and water by automatic drain or manually. Thus, we get the pure compressed air.
