Companies
Hangzhou Chunlai Technology CO., Ltd.
Products
Zetian - Model HM-100(I) - In-Situ ...

Zetian - Model HM-100(I) -In-Situ Hygronom Analyzer

FromHangzhou Chunlai Technology CO., Ltd.

SHARE

Hygronom is used to measure humidity of flue gas discharged by pollution source, based on which, converts wet flue gas concentration into dry flue gas concentration. In addition, it can also be used for industrial online humidity monitoring. HM-100(I) is installed on flue or stack via flange and output humidity as well as temperature signal by 4-20mA or RS232.

Most popular related searches

dust emissions monitoring

emissions monitoring

humidity measurement

monitor humidity

humidity monitoring

Adopt imported sensor with high performance index and reliability
Probe is with heat tracing function, avoiding condensate water in flue damaging sensor
Digital processing, strong anti-interference

It can be applied in humidity measurement and control in various industries including printing & dyeing, ageing, drying, tobacco, wood, paper-making, chemicals, pharmaceuticals, fiber, textile, vegetable &food processing, etc. Matched with CEMS, it can also be used in occasion of dust emission monitoring, monitoring and control in desulphurization & dust removal process of flue gas, etc.

Humidity range: 0~40% (VOL), 0~100% (VOL)
Temperature range: 0~180℃
Accuracy: ±2%F.S.
Response time:<6s (T90)
Temperature limit of flue gas:<150℃
IP grade: IP54
Ambient temperature: -10℃~55℃
Service life of humicap: >5 years
Output signal: 2x4-20mA (load: 500Ω) and 1xRS232
Humidity alarm output: 2xRelay output
Power: 220VAC, 40W
