Kotech - Model KMT-z2 -Inclined Metallurgical Microscope
Kotech Export offers a range of Metallurgical Microscope which is also known as optical microscope which is differnt from other microscopes in the method of the specimen illumination. This device is used to observe the minute details of specimen which can not be seen by naked eye. The microscope is fitted monocular observation tube inclined at 45 with quadraple revolving nose piece, graduated mechanical stage, bright field horizontal illuminator with centering provision, field and aperture diaphragm and slots for dropping filter. This product model is supplied with variable light control transformer. This Microscope is packed in moulded styrofoam box, with operation manual, dust cover and cleaning cloth. Wooden cabinet with lock and key are also available according to the customers need.
- Magnification: 25x-450x
- Observation: Monocular inclined 45° and rotatable 360° inter-changeable with straight tube for micro-photography/ imaging
- Stage: Horizontal Mechnical Stage 120x140mm. with fine vernier graduation. designed with convenient coaxial adjustment for specimen manipulation
- Focussing: Coarse and fine focussing by conveniently placed separate knobs. 1 div. =0.002 mm
- Illumination: Incident bright light through Epi-illuminator 6V - 20W Halogen lamp wih lris diaphragm and filter slot. continously variable luminasity
- Nose Piece: Quadruple revolving nose piece with positive click stop
- Objectives: Achromatic - M5x, M10x & M45x (S.L)
- Eyepieces: Huygenian 5x & wide field 10x
