Asmik - Model SUP-ORP6.0 -Industrial pH Meter

• Product: ORP meter controller, Redox monitor
• Model: SUP-ORP6.0
• Measure range     ORP: -1000 ~1000mV, ±1mV
• Measuring medium: Liquid
• Input Resistance: ≥1012Ω
• Temp compensation: Manual/ Auto temperature compensation
• Temperature Range: -10~130?, NTC10K or PT1000
• Communication: RS485, Modbus-RTU
• Signal output: 4-20mA, maximum loop 750Ω, 0.2%FS
• Power supply: 220V±10%,24V±20%,50Hz/60Hz
• Relay output: 250V, 3A

SUP-ORP6.0 Industrial online ORP meter controller is a multivariable analyzer used for measuring/controlling the ORP with different temperature. The function is switchable on the device itself. Depending on the measured variable, combination electrodes (e. g. ORP sensors) or split versions (glass electrodes with a separate reference electrode) can be readily connected.

• Automatically Temperature Compensation
• Directly switchable to ORP or pH
• Large LCD display with background lighting
• pH or ORP sensors can be connected thanks to the sensor supply integrated in the output
• Using the setup program: user-friendly programming
• 4-20mA analog output
• RS485 communication
• Relay output
