Packo - Model ICP1 Series -Industrial Stainless Steel Centrifugal Pump
FromPACKO INOX LTD
The Packo stainless steel centrifugal pumps of the ICP1 series are the “best value for money” industrial pumps. They have investment cast open impellers. This series achieves an overall high efficiency, leading to a lower energy consumption for your production process. Thanks to its modular concept it also guarantees an easy maintenance.
Most popular related searches
stainless steel centrifugal pump
industrial stainless steel centrifugal pump
centrifugal pumping
centrifugal pump
stainless steel pump
industrial pump
process pump
industrial stainless steel pump
textile water treatment
centrifuge
Industrial process pump with limited options
- Max. flow: 55 m³/h
- Max. head: 37 m
- max. product viscosity: 1000 cP
- max. motor power: 5.5 kW
- Pressed stainless steel with minimum thickness of 3 mm
- Investment cast impellers
- Large seal cavity to guarantee liquid circulation around the seal
- Monobloc execution with std. IEC motors
- High pump efficiency resulting in lower energy consumption
- Low NPSH values: less risk on cavitation
- Electropolished: higher resistance against corrosion
- Easy construction and easy maintenance: less downtime
- Easy to install
- Solid impellers compared to low cost spot welded versions
- Standard components
The ICP1 pumps are mainly used for pure as well as for slightly contaminated liquids.
They are often used as a process pump in textile industry for washing textiles, for water treatment, but also for handling solvents, alcohols and chemicals.
Performance:
- max. flow rate: 55 m³/h
- max. differential head: 37 m
- max. inlet pressure: 6 bar
- max. liquid viscosity: 1000 cP
- max. temperature: 140°C
- impeller type: open
- max. free passage: 18 mm
- max. motor power: 5.5 kW
- max. speed: 3000/3600 rpm
- available frequency: 50/60 Hz
