Dianyang - Model SR-19 -Infrared Thermal Imaging Module
Shenzhen Dianyang Ethernet SR series infrared thermal camera is a small-size radiometric infrared thermal imager. The product adopts imported detectors, with stable operation and excellent performance. It is equipped with unique temperature calibration algorithm and easy-to-use user interface. It is small in size, light in weight and rich in interface. It is suitable for quality control, heat source monitoring, security night vision, equipment maintenance etc.
Shenzhen Dianyang Ethernet SR series infrared thermal camera is a small-size radiometric infrared thermal imager. The product adopts imported detectors, with stable operation and excellent performance. It is equipped with unique temperature calibration algorithm and easy-to-use user interface. It is small in size, light in weight and rich in interface. It is suitable for quality control, heat source monitoring, security night vision, equipment maintenance etc.
SR Series Ethernet infrared thermal cameras are equipped with feature-rich client software and an easy-to-use SDK package that can be used to meet differentiated application needs, whether used alone or in a secondary development.
- SR series Ethernet infrared thermal cameras include power input, Ethernet, GPIO, serial port and other electrical interfaces to meet different industrial application requirements.
- DC12V wide voltage, allowing input power of 9~15V, ripple less than 200mV DC power supply, internal overvoltage and reverse connection protection, input voltage is too high will cause the protection circuit to fail.
- RS232-TTL supports 3.3V level standard UART communication standard, which can be connected to PTZ, PC, GPS module, etc.
- Control 12V motorized lens
- Support IO input trigger
- Support RTSP, universal playback software can directly play the video
- Support mainstream brand NVR supplier recording storage.
- With professional analysis software and SDK development kit to meet the requirements of secondary development and independent use.
- Clear image, high temperature measurement accuracy, support -20 ° C ~ 350 ° C
