Jensprima Instruments Limited

- Model 6800 Plus - Intelligent Controller

From

0

InnoCon 6800 plus intelligent controller designed for water treatment and industrial process monitoring, with innoSens series of electrodes can be measured: pH, ORP, conductivity, resistivity, TDS, dissolved oxygen, residual chlorine, chlorine dioxide, ozone, fluorine Ions, chlorine ions and so on. English menu, automatic temperature compensation, a variety of installation methods, standard 4-20mA / RS485 Modbus and a variety of control functions output.

  • pH / ORP
  • Conductivity
  • Resistivity
  • TDS
  • Dissolved oxygen
  • chlorine
  • chlorine dioxide
  • ozone
  • Fluoride ions
  • Chloride
  • Temperature

  • Waste water
  • Tap water
  • Process water
  • Boiler
  • Disinfection process
  • Reverse osmosis
  • Laundry room
  • Cooling tower
  • Fermentation
  • Purified water
  • Irrigation
  • Rivers and lakes
  • pool
  • Aquaculture
  • Sea water

Large-screen backlight LCD

  • 240 x 160 dot matrix display
  • Display of measured value, temperature value, relay status

The latest wide power input, super anti-interference design

  • Wide power input: 90 ~ 260VAC
  • Pluggable terminals for easier connection

Flame retardant plastic bite flower shell, more texture

  • JENSPRIMA exclusive color, more texture
  • Removable shell design, maintenance and replacement more convenient

Password protection, to prevent unauthorized operations

  • Set mode password: 0022
  • Calibration mode password: 0011

Avariety of installation methods

  • Wall / panel / pipe installation

RS485 output

  • Standard Modbus RTU communication protocol. The baud rate is fixed at 9600.

New calibration steps to help reduce operational errors

  • English and Chinese menu, easy to operate
