Innovation - Model INCW-FS20 -High Precision In Line Check Weigher
The length of the weighing section of this type of product is shorter than that of the standard type; it shortens the invalid weighing time in the middle and makes the rapid selection scale faster and more efficient. This model is suitable for a length less than 200mm.
Most popular related searches
Product testing.
The adjustable splint device is used in the front part of the equipment to prevent the product from rolling in a disorderly way and ensure higher accuracy. The adjustable splint device is suitable for the detection of round, oval and egg shaped products.
Select the technical parameters of the scale:
- Scale of weighing: 1kg-20kg
- Weighing precision: + 10g
- Weighing table size: long: 600mm; width: 300mm;
- Display resolution: 0.5g
- Sorting speed: 25 packs / minutes
- Belt speed: 10-40 meters per minute
- The height of the conveyer belt from the ground: 750mm + 50mm (confirmation)
- Delivery direction: operating interface from left to right
- Motor power: alternating current 220 volts (50/60 Hertz)
- Working temperature: from 0 C to 40 C
- Humidity: 90% relative humidity (no condensate)
- The material of the scale body is made of stainless steel
- Whole machine size: long: 1200mm; width: 650mm; height: 1350mm + 50mm
