Darlly - Model Has-Cleen -Integrated Gas Filters
FabPure Depth-Stack Filter Cartridges are a new type of filter cartridge using depth filter sheets. It is designed using a double separator concept. The Separator design increases the total stability of the filter cartridges as the separators fully support the sheet material. This design also prevents filter sheet deformities after heat treatment and adverse effects from hot sanitation. It is manufactured with rigid external clips to prevent damaging filter sheets during module loading and unloading while allowing for easy and reliable handling.
Most popular related searches
filter cartridge
depth filter sheet
gas filter
cartridge filter
depth filter
capsule filter
gas filtration
depth filter cartridge
hydrophobic PTFE membrane
stack filter
- High flux and low pressure loss
- The natural hydrophobicity of PTFE membrane enables it to filter gas with very huge filtration flux and very low initial DP. PTFE membrane has excellent particle trapping capacity, providing particle retention efficiency up to 99.99%. Removal rating up to 0.003μm to achieve fine filtration of pipeline gas.
- Semiconductor Grade Housing Treatment
- The inner surface of the housing is electrolytically polished with Ra less than 0.1μm. The inner surface is corrosion-resis-tant and mirror-clean.
- Excellent chemical compatibility
- PTFE is used as media and high purity SUS316L as the housing material. Both of them have excellent corrosion resistance and can be used for active gas filtration. At the same time, ensure the stable filtration of gas under high temperature and high pressure.
