IBA - Model 10XF-3CT -Ionization Chamber

Key benefits

• Flat energy response covering the total active chamber length
• High confidence with individual factory calibration sheet

10XF-3CT is the ionization chamber for measurements on CT scanners

• Air ionization chamber
• Homogeneous sensitivity over the entire active length of the chamber
• Provided with protective shielding (guarded)
• Delivered with an individual calibration document

Material

• External electrode: C552
• Inner electrode: C552
• Connector: 7-pin multi plug connector
• Cable: 2 m flexible, low noise

Size

• Active volume: 3 cm3
• Total active length: 100 mm
• Outer diameter of the external electrode: 9 mm
