JC - Model 715 / 730 RB -Floating Ball Valve
BODY: Carbon steel, Stainless steel, Low temperature carbon steel, Duplex, Special Alloys, Other materials under request. SEATS : PTFE, RPTFE, PEEK, DEVLON, NYLON, Other materials under request. TRIM: 316, 410, MONEL, Other materials under request.
Most popular related searches
DESIGN FEATURE
End entry, reduced bore. Fire-Safe certified, floating ball, blow out proof stem, flanged connections. Non-removable antistatic devices assure electric continuity between ball and body through the stem. All wetted component materials meet NACE MR.01.75 latest edition as standard. Cavity pressure balancing hole avoids overpressure in the cavity with the valve in open position. Asbestos free. CE and ATEX marked.
APPLICATION
- Refinery
- Chemical
- Petrochemical
- Power plant
- Gas
