JONO - Model 1FDS1590A/1FDS1560A -Solid Waste Treatment Equipment Sorting Machine Disc Separator for MSW Organic Waste
As one of the most important sorting machines,disc screen separates material into big-sized material and small-sized material.By changing the screening size,you can always separate out what you need.Typically,it is applied in treating MSW,in process of which organics or RDF can be well separated out.
- After-sales Service: Instruction for Commissioning and Maintenance
- Warranty: 1 Year
- Condition: New
- Certification: ISO, CE, SGS
- Automation: Automatic
- Screw: mechanical sorting
- Customization: Available
- Model: NO.: 1FDS1590A/1FDS1560A
- Treatment: mechanical: sorting
- Lead Time: 1-3: Month
- Customize: Welcome
- Color: Black/: White/Orange
- Weight: 3100kg
- Shaft: quantity: 18
- Shaft: diameter: 450
- Throughput: capacity: 70-150: m³/h
- Screening: rate: 80%-95%
- Transport: Package: Container
- Specification: 1FDS1560A
- Trademark: Jono
- Origin: Jiangsu,: China
- HS Code: 8464909000
- Production: Capacity: 10/Month
Driven by the electrical motor,main shafts running in one direction in the screening chamber.When material goes into the disc screen,the material is firstly scattered by the rotating disc plates.Then along with the movement of material on the disc plates,the small-sized material drops down through the screening hole formed by the neighbor main shafts and the neighbor screen plates.Material that are bigger than the screen hole will pass disc screen.With the knowledge that different material has different size range,the material can be separated by this size-controlled screening.
