Klaermax - Model Mobil -Container Wastewater Treatment Plants

The heart in the container – the technology
The system comes in a 20-foot sea container that can be easily transported by truck.
The pump station consists of the tank (PE-HD), a cutter wheel pump and a low voltage control unit.

Four rectangular, space-saving tanks made of food-grade polyethylene are used. Each of the tanks has a capacity of 4000 liters and are resistant to all wastewater ingredients. Stability is ensured by the galvanized steel bandages. As compressors we use two Nitto LAM-200 piston compressors (215 W). Piston compressors are much quieter than diaphragm compressors. Furthermore, the operational reliability is increased and a consistently high pressure is applied. The reactor is aerated by means of disk aerators. These diaphragm aerators allow fine-bubble discharge of the air.

There are no moving or electrical parts in the vessel. The complete technology is installed outside the tank for easy access and does not come into contact with the wastewater. This reduces the susceptibility to failure.

Spare parts and control
Spare parts for the conversion kit are easy to acquire and quick to replace. The control cabinet in the front part of the plant houses all the necessary electromechanical components (control, compressor and solenoid valves). The „Pro“ control system controls the entire cleaning process. It can be used to adjust operating times on site or to view running times. In addition, the control system has an automatic vacation and economy mode with many extras.

Klärmax Container

• Including pump station
• In 20-foot sea container
• Mobile transportable by truck
