LabRAM - Model II -Advanced Processing and Development Platform
The LabRAM II’s set of design and features reflects users’ critical requirements, delivering processing speed, mixing power, and optimal parameters to scale production RAM machines. With an integrated touch-screen controlled operating system that enables recipe development and data management, and optional processing accessories including vacuum systems and temperature-controlled vessels, the LabRAM II gives users better results, improved efficiency, and new product opportunities.
- Mixing and processing any combination of
- Solids/Powders – from nano-scale, and higher
- Liquids/Gases
- Viscous/Slurry materials
- Coating, Milling, Grinding processes
- On-board control of optional processing accessories
- Automatic Vacuum System
- Jacketed Vessel Temperature Control
- Spray-coating Functions
- Develop, store, and secure up to 100 recipes
- Monitor mixing parameters in real-time
- Download processing data for analysis
- Up to 2.2 lbs (1,000 grams) payload processing capacity
- Integrated touch screen operating system
- Intense, but gentle acoustic mixing for rapid, highly repeatable, ultra-high quality results
- Fully enclosed, interlock-able acoustic mix chamber
- Height-adjustable vessel holder accepts many vessel types
- Multiple level security and access control
General:
Model: LabRAM II
Technology: ResonantAcoustic® Mixing
Intended Use: Laboratory, Development, Bench-scale Batch Mixing
Unit Dimensions: 33″ H x 29″ W x 24.5″ D (cm: 83.8 x 73.7 x 62.2)
Unit Weight: 260 lbs (117.9 kg)
Country of Origin: USA
Certifications: CE Certified, UL Certification Available
Operating Specifications:
Maximum Payload Capacity: 2.2 lbs (1 kg)
Compatible Materials: Solids, Liquids, Slurries, High Viscosity Pastes
Max Vessel Acceleration: 100g at 60 Hz
Max Operating Noise: < 70 db at 3′
Sealed Acoustic Chamber: Yes
Included Vessel Holder Assembly: 5″ Diameter – Adjusts for 2.5″ to 5″ High Vessels
Included Vessels: 1 x Polypropylene 4 oz
1 x Polypropylene 8 oz
1 x Polyethylene 4 oz
1 x Polyethylene 8 oz
Control Specifications:
Human Machine Interface: Full Color Touch Screen
Operating System: Proprietary On-Board
Programable Mix Recipe Storage: Yes
Data Logging: Yes
Remote Operation: Yes, with RAMware3
Power Specifications:
Required Voltage at 50/60 Hz: 100-120 / 200-240 VAC
Current Required: 1000 watts
Power Cord: Region-Specific Cord Included
