Laizhou Dongsheng - Wafer Type Butterfly Valve

The range of industrial butterfly valves from Laizhou Dongsheng Valve Co., Ltd. includes lug type, flanged, and wafer type designs, all engineered for precision and reliability in flow control applications. With working pressures rated at 1.0/1.6 MPa, these valves operate efficiently within temperature ranges dictated by their elastomers, such as NBR and EPDM. They are compatible with a variety of piping standards, including DIN, BS, JIS, and ANSI, making them versatile for global applications. Designed for use with mediums like fresh water, sea water, oils, and certain food substances, they undergo rigorous testing per standards like DIN3230 and API598 to ensure performance and safety. Key technical features include a disc-type opening mechanism, lockable handle options, and removable seats, with ductile iron construction supporting temperatures between -5°C and +180°C. These valves offer low material consumption and compact dimensions, lending themselves to cost-effective production and efficient installation.
