Marlo - Model MHC Series -Large Industrial Applications Water Softener Systems

FromMarlo, Inc.

SHARE

The Marlo `MAT` Series is designed for commercial and industrial applications demanding continuous soft water supply. All systems are twin-alternating configurations with one tank in regeneration or stand-by at all times. Individual tank capacity ranges from 15,000 grain to 450,000 grain with continuous flow rates of 1-45 GPM.

Most popular related searches

water softening system

softening system

water softening

cation exchange resin

remote water meter

electronic water meter

programmable logic controller

Epoxy lined and prime exterior finished carbon steel pressure vessels. Non-ASME construction with 100 psig working pressure.
High capacity, sulfonated polystyrene cation exchange resin in sodium-form.
Galvanized steel face-piping assembly with cast iron, normally-open, "Y" pattern diaphragm control valves. Filters with service piping 6" and larger utilize flanged carbon steel face-piping and double-acting butterfly service control valves.
Pilot stager valve controller for automatic regeneration operation. Pre-wired in a NEMA-4X enclosure with an adjustable timeclock for regeneration initiation.
Self-adjusting flow control to maintain accurate backwash rates.
Pressure-compensated brine injector for correct brine flow and concentration.
PVC media-retaining underdrain distribution system in either hub-radial or header-lateral configurations for minimal pressure drop and proper regeneration.
Rigid, polyethylene or FRP brine tanks with wet-salt storage and water re-fill valves

ASME constructed, stamped, and certified pressure vessels for varying working pressures.
"Safety Blue" finish painted vessel exteriors. Alternative colors are available.
Electronic water meters for volume initiated regeneration, flow display, and totalization.
Twin alternating configurations with remote water meter (mechanical or electronic) and electro-mechanical controller for continuous soft water supply.
`MX-III` Electronic programmable cycle controllers for systems up to 4 softener tanks. Flexible system control for almost any configuration using timer or volume initiated regeneration. "Additive Flow Feature" for automatically bringing additional tanks on-line as service flow increases.
Inlet/outlet pressure gauges and sample valves.
Sch 80 PVC face-piping and thermo-plastic diaphragm valves (2-3" service).
Sch 80 PVC face-piping and butterfly valves (3-8" service).
304/316 Stainless steel pressure vessels, face-piping, and internal distributors.
Manual system valves for operator-performed regeneration cycle.
Bulk brine storage vessels and brine pump skid systems.
Programmable Logic Control (PLC) electrical packages.
Skid mounted, pre-piped, and pre-wired systems (for single/multiple softeners).
`SRS` Salt Recycler System for 25% less salt consumption without loss in treated water quality. Requires additional control valves, enhanced stager controller, and modified brine tank.
