LCI - Model T Series -Incubating System

SHARE

Incubator T Series is an intuitive and integrated stage-top live cell incubator system, maintains all essential parameters in a physiological state ensures optimal experimental conditions for cell viability on microscope for the purpose of ‘ happiness for the cells and success for researchers.’ It is a system that can maintain the right temperature and pH for cells to live, or create and maintain an environment suitable for the experimental characteristics, keeping live cells healthy during imaging on a microscope or for days to weeks. Incubator T Series provides precisely controlled conditions including optimized temperature, humidity, CO2, and optional O2 levels for long-term live cell imaging with various Magnetic Imaging Chambers fitted perfectly. The temperature of the incubator main body, incubator cover, humidifier, lens warmer, and gas concentration is controllable and recordable. The gas gradients are programmable by CCP(Computer Controlled Program) software.

Most popular related searches
live cell imaging
digital temperature controller
sample holder
objective lens
sample temperature
water reservoir
incubator
cell culture consumables
well plate
cell culture

Automatic Sensing Mode

Temperature control by 3 types of heating feedback

External Mode [World-Wide 1st]
The optimal temperature control algorithm that minimizes temperature deviation by detecting changes in the temperature outside the incubator automatically adjusts the temperature of the incubator optimized for cell growth.

Sample Mode
By sensing the sample temperature, the optimum incubator temperature is adjusted.

Manual Mode
By setting the temperature desired by the user, various environments for researchers’ purpose can be performed.

  1. Localization
  2. Cell differentiation
  3. Cell viability & Cytotoxicity
  4. Phagocytosis & Cell Fusion
  5. Neurite outgrowth/process extension
Incubator
Incubator offers optimal on-stage cell culture environment by maintaining the temperature, humidity, and pH during time lapse imaging. Thermal design of the incubating cover and body are designed to provide heat inside the incubator. For better heat insulation and durability, the incubator body is designed with heating plate to maintain the temperature, while incubator cover composed of built-in dual layered glass traps the heat inside.
Incubator TS (Standard)
  • Stable Sliding & Whole opening cover for user convenience
  • Fit to 26mm & 30mm W.D. of condenser
  • Dual-layered incubator cover for heat insulation
    Top: Tempered glass for breakage-free using Gorilla 6 Glass
    Bottom: ITO Glass for heating
  • Magnetic combine method of cover & body makes high sealing and better stability
  • Temperature control by 3 types of heating feedback 3-channel fluidics port
  • Sample holder with Magnet Fixing Cover
Incubator TL (Light)
  • Lighter model of the Incubator T Series
  • Recommended for weight sensitive stage such as Piezo Stage
  • Only whole opening cover available
Incubator TW (Wide)
  • IncubatorT Wide has a built-in Water Reservoir, which provides excellent performance of maintaining humidity even when using commercial well plate.
  • Best for Humidity Maintanance
  • Long-term Imaging available with wellplate
Water Reservoir Type Sample Holder
The water reservoir around the sample holder improves the maintenance of humidity, preventing media from evaporation.
  • Compatible with all types of cell culture consumables
  • Commercial well plate can be used without a additional structure
  • Magnetic Fixing Cover makes it possible to load the sample more easily and stably
Controller
Temperature Controller
Provides stable and precise control of sample temperature for long-term imaging. Using PID Control, it enables maintaining the temperature of all heating parts including incubator cover, incubator main body, humidifier, and lens-warmer
  • 3 types of heating control : External, Sample (K-type), Manual sensing feedback
  • 4 heating channels: Incubator cover, body, humidifier, lens warmer
  • Simple cable attachment with color connector
  • Stable and durable temperature distribution
  • Real-time graph and alarm function
  • Real-time thermal response
  • PID control of all parameters
Gas Mixer
Provides accurate concentration gas of CO2, N2, or O2 for research application
  • Available with 3 types of gas controller
  • Solenoid valve and a reservoir for uniform gas blends
  • PID control system regulates gas concentration
  • Internal air pump for a stable gas flow
  • Straight quick connection by tubing fittings
C-type Cable & Connector
  • Simplicity and Standardization
  • Easy installation
  • Intuitive connection
Humidifier
The role of the humidifier is to generate and help incubator to maintain relative humidity, and prevent evaporation which can cause cell damage. CO2 gas flows into incubator through heated water controlled by the humidifier sensor. The rate of air-bubbling can be used to check the flow of gas.
  • Keeps saturated humidity in the incubator
  • Maintains osmolality of medium by preventing evaporation
  • Short heating time and accurate temperature feedback by heater and sensor installed inside the humidifier which is directly located in the water
  • Backflow protection filter to prevent backflow of water from gas leakage or careless use
  • Easily replenish water without removing the lid by separate water replenishment port
Lens Warmer
For high-resolution imaging, it is necessary to control the temperature of the immersion objective lens. Oil, glycerin, or water acts as a thermal coupling medium which draws heat away from the specimen. To avoid heat loss, wrap the lens warmer onto the objective lens to generate and maintain a proper temperature. Its silicone band fits to all types of objectives.
  • For high-magnification & high-resolution imaging
  • Specialized silicone material heating band wraps the lens without gap, preventing thermal dissipation from sample temperature
  • Flexible silicone material heating band fit to all objective lens
Remote Touch Pad
Android tablet PC provides intuitive graphical screen for all of parameters required to control incubator system
  • Controls system and all parameters by smartphone and other devices
  • Provides on-line troubleshooting
  • Uses GUI(Graphical User Interface) with intuitive and easy control
  • GUI for real-time temperature and control
  • Automatically save and check real-time data with PC
  • Output data to PC through USB A cable
