Lev-Co - Model PCH-1 - 1500 CFM - 02-003 -Portable Self-Cleaning Dust Collector

This single cartridge dust collector has a small shop footprint and is easily movable. The unit has a flow rate of 800 to 1500 CFM and comes with an easy-to-use push button self-cleaning system.

Main Options include:

• Extraction Arms
• Filter Options
• Fan/Motor Upgrades or Options
• Sound Attenuation
• Preventative Maintenance Pressure Gauges
• Variable Frequency Drives
• Fan, Light & Other Electrical Accessories

• 12, 14 &16 ga. welded steel cabinet with powder-coated finish
• Includes full-width handle
• Removable end cap for easy access to filter
• Removable back panel for access to direct drive motor/blower compartment
• Magnetic motor starter included
• Complete with a 7` EZ-Arm®
• 7” Ø hose, high flow extractor (with a damper)
• (1) Clean2® filter cartridges (150ft² of media)
• Manual VIBRA-PULSE® filter cleaning system built-in
• 1.5 HP TEFC motor
• Backward incline blower
• Removable 5-gallon external dust drawer
• 8” front wheels
• 5” rear swivel casters

• Complete, Self-contained Unit: Includes 7-ft. E-Z Arm® High Flow Extractor Arm, blower, and filter cartridge.
• Direct-drive Blower: Higher static pressure, longer filter life, and greater reliability; spark resistant; no belts or pulleys to replace.
• Non-electrostatic Operation: High reliability, low maintenance.
• Compressed filter mounting: Eliminates contaminant bypass of filters.
• Vibra-Pulse® Filter Cleaning System: Cleans filters 75% more effectively than reverse pulse systems.
• Low Profile Cabinet: Low center of gravity for easy maneuverability and arm positioning.
• Heavy-Duty, 12 ga 25-ft. Power Cord: Maximizes system portability and positioning during operation.

Top 5 contaminants/processes/applications:

• Welding Fume
• Grinding Dust
• Silica Dust
• Artifact Restoration dust
• Food and Pharmaceutical Dusts

Don`t see your contaminants? Give us a call! 1-888-862-5356 or Click our instant chatbox.

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.

PCH-1-1.5HP-1
800cfm portable cartridge collector with

• (1) 7` long E-Z Arm ® high flow extractor (WITH DAMPER),
• (1) CLEAN-2 ® cartridge filter (150 sq.ft. of media),
• Manual VIBRA-PULSE ® filter cleaning system,
• 1.5 Hp TEFC motor 115/230/1/60Hz (12/6 amps),
• Backward incline blower,
• Removable 5 gallon external dust drawer,
• 8 front wheels and 5 rear swivel casters. 70 dBA
• AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation prior to shipping.

PCH-1-1HP-1
700 cfm portable cartridge collector with

• (1) 7` long E-Z Arm ® high flow extractor (WITH DAMPER),
• (1) CLEAN-2 ® cartridge filter (150 sq.ft. of media),
• Manual VIBRA-PULSE ® filter cleaning system,
• 1 Hp TEFC motor 115/230/1/60Hz (12/6 amps),
• Backward incline blower,
• Removable 5 gallon external dust drawer,
• 8in front wheels and 5in rear swivel casters. 70 dBA
• AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation prior to shipping.

PCH-1-1.5HP-2
800 cfm portable cartridge collector with

• (1) 7` long E-Z Arm ® high flow extractor (WITH DAMPER),
• (1) CLEAN-2 ® cartridge filter (150 sq.ft. of media),
• Manual VIBRA-PULSE ® filter cleaning system,
• 1.5 Hp TEFC motor 230-460/3/60Hz (12/6 amps),
• Backward incline blower,
• Removable 5 gallon external dust drawer,
• 8 front wheels and 5 rear swivel casters. 70 dBA
• AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation prior to shipping.

PCH-1-1.5HP-3
800 cfm portable cartridge collector with

• (1) 7` long E-Z Arm ® high flow extractor (WITH DAMPER),
• (1) CLEAN-2 ® cartridge filter (150 sq.ft. of media),
• Manual VIBRA-PULSE ® filter cleaning system,
• 1.5 Hp TEFC motor 575/3/60Hz (1.5 amps),
• Backward incline blower,
• Removable 5 gallon external dust drawer,
• 8 front wheels and 5 rear swivel casters. 70 dBA
• AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation prior to shipping.

• Filter Options (when ordering with main unit)
• Extraction Arms
• Replacement Filters
• Sound Attenuation
• Preventative Maintenance Pressure Gauges (when ordering main unit)
• Variable Frequency Drives
