Eltek GenII - Model CB70 -Light, UV and Temperature Transmitter
FromEltek Limited
Flexible mounting options make the CB70 transmitter ideal for wall mounting or for locating inside a display cabinet with full pan and tilt adjustment. Other case colour options are available. This transmitter has an external configuration socket. N.B. this product replaces the GL70/GL70W.
Most popular related searches
LS50 light puck
- Dimensions: 33mm diameter x 8 mm height
- Lead length: 2m
LS70
- Dimensions: 73 x 50 x 30mm.
- Lead length: 2m
Common GenII Transmitter Specification
- RF specification: EN300-220
- RF power: 10mW
Environment specification
- Compliant to EN300-220: -10 to +55°C
- Actual: -30 to +65°C
- Humidity: 100% non condensing
- Environmental rating: IP40
- Dimensions (footprint): 78 x 41mm
- Transmission interval range: 1 sec to 4 hours
- Indicator (red LED): transmit active/on/off
- Control switch (concealed): test mode / hibernate
- Antenna socket: SMA
