Endura - Model Series 700 -Liquid Ceramic Insulation Coatings

• High dielectric strength (over 6,000 volts of insulation have been achieved with only 140 microns of coating thickness applied).
• High heat stability (up to 1,500°F)
• Improved surface hardness
• Resistance to salt spray corrosion (up to 1,000 hrs per ASTM B117)
• Scratch resistance
• Thin film deposits

Available in a wide array of colors, our Endura 700 Series cermaic insulation coatings have enjoyed considerable success across a wide range of industries and use applications, spanning everything from various commercial products, functional automotive components and military firearms.

Our liquid ceramic coatings go through the following processes:

Step 1: Removal of contaminants from top surface and sub-surface area.

Step 2: Proprietary equipment ensures removal of all contamination to optimize adhesion without altering part`s dimensional integrity.

Step 3: Ceramic particles, containing special proprietary reinforcements are deposited on to your substrates working surfaces.

Step 4: Liquid ceramic is thermally and chemically bonded to the base substrate through a proprietary vacuum oven bonding process.

Step 5: Liquid ceramic coating is complete.

• Coating Thickness - 0.001" up to 0.006" per surface
• Maximum Continuous Operating Temp. - 500 F
• Color - Purple
• 5% Salt Spray (ASTM B117) - Up to 1,000 Hrs.
• Pencil Hardness (ASTM D3363) - 7H
• Scratch Hardness (ASTM D3363) - 4H
• Adhesion Cross-Cut Tap (ASTM D3359) - 4B
• Mandrel Bend (ASTM D522) - Up to 180° rotation; 1/4" mandrel
• Impact (ASTM D2794) - 160 / 160 inch-lbs
