Mass Flow Online - Model Liqui-View - LVB-25-AD (9.0 .. 150 l/min) -Liquid Flow Meter
Low-Flow Vortex Flowmeter for Liquids: Fast response. Analog output (4-20 mA). Compact, light-weight, cost-effective construction. No moving parts; maintenance free. Low pressure drop. IP65 construction.
Most popular related searches
liquid flow metering
liquid flow meter
flow meter
vortex flow meter
pharmaceuticals drinking water
cooling water monitoring
ultrapure water
water monitoring
deionized water monitoring
deionized water
Model: Min: Max
- LVB-25-AD: 9.0 l/min: 150 l/min
- Display features:
- Local readout of actual flow rate
- Tilting display (180°)
- Bright, wide-angle and easy-to-read display - Makes liquid flows visible by Analog output (4..20 mA)
- No moving parts makes it:
- impervious to deposits
- maintenance free - Low pressure drop
- Mounting in any position
- Wide flow ranges
- Fast response
- Suitable for dirty water (circulating, well or waste water)
- Sustainable product design
- Low power consumption
- Lightweight and compact
The fields of application for this vortex liquid flow meter are diverse:
- Cooling water monitor
- Deionized water (RO/DI skids)
- Ultra pure water distribution (medicare, biotech, semiconductor, pharmaceutical)
- Drinking water
