Lite-Span - Aluminum Covers
Hallsten Corporation`s Aluminum Lite-Span Covers provide gaseous emissions containment for clarifiers, sludge holding tanks, bio-towers, aeration basins and any number of other storage vessels found in projects of environmental importance. Innovative and cost effective, the Hallsten Corporation Aluminum Lite-Span Cover represents a breakthrough in modular design and structural efficiency. Hallsten Corporation pioneered the use of extruded aluminum for cover construction. Although imitated, the patented design of the Hallsten Corporation Aluminum Lite-Span Cover has never been equaled. Simply put, there is no `or equal`. The Hallsten Corporation Aluminum Lite-Span Cover is the most innovative and cost effective cover on the market, period.
- Air Tight
- Visually Appealing
- Structurally Superior
- Chemical Resistant
- Energy Saving
- Maintenance Friendly
- Easy to Install
Once installed, the patented double interlocking deck component combined with interlocking beams form a substantially air tight structure. Our unique fabrication techniques and the close design tolerances assure that gases and odors are safely contained. Polymer seals are used between adjoining panels and at the cover perimeter. These replaceable seals allow the thermal expansion and contraction of the cover without compromising the integrity of the joints. Our unique hatch and penetration details provide minimal leakage through these normally troublesome components.
The patented design of the Hallsten Corporation Aluminum Lite-Span Cover is structurally superior to any
competing cover. Each modular panel can be individually constructed to provide for high load pedestrian paths and working areas. Only Hallsten Corporation can provide a cover with sufficient strength to withstand concentrated loads in excess of 1000 pounds without permanent deformation. Surface dishing from concentrated load over-stressing, so common with bent metal or inferior component based covers, is eliminated with the Hallsten Corporation Aluminum Lite-Span Cover system. The panel and beam configuration allows Hallsten Corporation to design cover structures with extremely high distributed load capacity. The modular configuration provides for unlimited geometric options. Covers can be configured in any shape or size; circular, rectangular or irregular.
The Hallsten Corporation Aluminum Lite-Span Cover is the result of a focused effort to design an aluminum cover specifically intended for environmental applications. The design effort has resulted in over a dozen United States Patents. These patents not only cover the primary structural design of the Hallsten Corporation Aluminum Lite-Span Cover but also many of the unique features found only on this cover system. Included in these features are the Gear Hinged Access Hatch Panel and the Double Seal Gutter. The patented Gear Hinged Access Hatch Panel allows any individual panel on a cover system to become a fully opening access hatch. This effectively allows for a cover system that provides total access to the tank below. The Double Seal Gutter provides a patented continuous double seal for irregular or damaged concrete often found in basin retrofit installations. Both of these features are only found on Hallsten Corporation Aluminum Lite-Span Covers. The modular structural design allows Hallsten Corporation to construct covers of any size required on projects of this type.
The low profile of the Hallsten Corporation Aluminum Lite-Span Cover provides for a very clean aesthetic appearance. Each component of the system has been designed with an eye towards this aesthetic. A camber is designed into every cover to assure proper drainage of rainwater. This camber can be increased or decreased to vary the aesthetic appearance. The standard mill finish of the aluminum surface components includes a ribbed texture that disguises the unwanted metal appearance common with bent sheet metal covers. Optionally, the cover can be sandblast finished or anodized.
CHEMICAL RESISTANT
The Hallsten Corporation Aluminum Lite-Span Cover is fabricated entirely of 6061 T6 alloy corrosion resistant aluminum extrusions. Every seal used between adjoining panels is of a corrosion resistant polymer. Even the patented connector between the beam and the panel is a structural polymer that is chemical resistant and will not weaken or corrode. A mechanical and replaceable Santoprene seal isolates the cover perimeter from the concrete or steel tank wall. No foam tape or caulk is used.
ENERGY SAVING
A flat cover, when used with odor control units such as scrubbers and other air handling equipment significantly reduces energy costs. By reducing the volume of the enclosed gases, the size of blowers, fans, ducts and scrubbers can be reduced with a proportional savings in power consumption. This creates an overall savings, both in initial construction cost and operation. If required, the Hallsten Corporation Aluminum Lite-Span Cover can be provided with insulation to minimize heat losses in thermally sensitive processes.
MAINTENANCE FRIENDLY
The modular design of the Hallsten Corporation Aluminum Lite-Span Cover makes maintenance substantially easier than our competitors bent metal or inferior component based covers. The Hallsten Corporation Aluminum Lite-Span Cover`s modular sections can be easily removed because there are no corroded sheet metal screws, frozen nuts or wedged seals to hinder access. Each panel can be lifted by hand with only the force of its weight unlike some of our competitors units that require special lifting equipment to pry each panel loose. Each Hallsten Corporation Aluminum Lite-Span Cover is as easy to remove as it is to install assuring total access to process equipment. An optional temporary handrail system is available to protect maintenance workers. This handrail system clips to the beam component of the cover system and is easily installed at any location where a panel has been removed or an access hatch panel has been opened.
The Hallsten Corporation Aluminum Lite-Span Cover includes an integral non-skid surface. Every panel and beam, regardless of position or load capacity, incorporates this surface. Slip resistance is critical to the safety of all personnel.
