Logotronic GmbH

LogotronicModel Gealog RS485 -Water Temperature Sensor

SHARE

The design of the Gealog RS485 water temperature sensor incorporates Logotronic`s many years of experience. The precision NTC thermistor used is in a tube with a diameter of only 2.2 mm and therefore reacts to changes in water temperature within a few seconds. A robust plastic protective basket prevents mechanical damage to the temperature sensor. As with all Logotronic products, the high-quality workmanship and technical design ensures use for many years with minimal costs of ownership.

Most popular related searches
Precise water temperature measurement with small time constant
  • Precise temperature measurement with NTC (+/- 0.1°)
  • Small time constant, installation of the NTC in stainless steel tubes with diameter 2.2mm
  • Measuring electronics directly at the sensor, no measured value falsification due to probe cable
  • Gealog RS485 fieldbus interface for connection to Gealog data collectors
  • High quality durable waterproof design by using stainless steel case.

The picture shows the miniaturized NTC measuring resistor.
