LS - Cast Resin Transformer
LS cast resin transformer takes pride in the ability to offer a wide variety of designs and configurations necessary to satisfy customer needs. Computer and CAD/CAM systems are used for quick and accurate design and manufacturing to meet specific customer requirements.
Most popular related searches
fire fighting system
environmental contaminant
oil spill
mold prevention
fire prevention safety
fire prevention
fire fighting
Short Circuit Strength
- Vacuum-cast with epoxy resin with excellent electrical and mechanical strength
Easy to Maintain
- No oil exchange and firefighting equipment
Overload Tolerance
- Excellent overload tolerance compared to the oil immersed type transformer
Eco-friendly
- No environmental contamination due to oil spills
Suitable for Power Supply to Equipment with Rapid Changing LoadsHumidity Resistance
- Coils are vacuum-molded to prevent entry of moisture
Non-combustibility
- Uses non-combustible epoxy resin to prevent fires
Excellent Impulse Voltage Strength
- Installation place : Indoor(Enclosure needed for outdoor)
- Applicable standard : KS C 4311, IEC 60076-11, IEEE C57.12.01
- Frequency : 60, 50
- Insulation kind : F type, H type
- Coil temperature rise : 100K, 125K
- HV rated voltage(kV) : 33, 22, 10, 6
- HV tap voltage(V) : 5 Taps (±2x2.5%)
- LV rated voltage : 400V
- Angular displacement : Dyn11
